PROCESSOR
Supports 10th Gen Intel® Core™ Processors, 11th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors
CHIPSET
Intel® H510 Chipset
MEMORY
2x DDR4 memory slots, support up to 64GB1
Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel® CPU (by JEDEC & POR)
Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel® CPU (by JEDEC & POR)
Supports Dual
Channel mode
Supports non
ECC, un
buffered memory
Supports Intel® Extreme Memory Profile (XMP)
EXPANSION SLOT
1x PCIe x16 slot (From CPU)
Support up to PCIe 4.0 for 11th Gen Intel® CPU
Support up to PCIe 3.0 for 10th Gen Intel® CPU
2x PCIe 3.0 x1 slots (From PCH)
ONBOARD GRAPHICS
1x VGA port, supports a maximum resolution of 2048x1536 60Hz, 1920x1200 60Hz
1x HDMI 1.4 port, supports a maximum resolution of 4K 30Hz
STORAGE
4x SATA 6Gb/s ports (From H510 Chipset)
USB
Intel® H510 Chipset
4x USB 3.2 Gen 1 5Gbps ports (2 Type
A ports on the back panel, 2 ports available through the internal USB connector)
6x USB 2.0 ports (4 Type
A ports on the back panel, 2 ports available through the internal USB 2.0 connector)
AUDIO
Realtek® ALC897 Codec
7.1
Channel High Definition Audio
LAN
1x Realtek® RTL8111 Gigabit LAN controller
INTERNAL CONNECTORS
1x 24
pin ATX main power connector
1x 8
pin ATX 12V power connector
4x SATA 6Gb/s connectors
1x USB 3.2 Gen 1 5Gbps connector (support additional 2 USB ports)
1x USB 2.0 connector (support additional 2 USB ports)
1x 4
pin CPU fan connector
1x 4
pin system fan connector
