CPU
Built in with an Intel® Quad
Core Celeron® N5105 SoC (2.0 GHz) * Do not disassemble the onboard SoC and the heatsinks by yourself to avoid damage to these components.
4 MB L3 Cache
Memory
2x DDR4 SO
DIMM sockets supporting up to 16 GB of system memory * If only one memory module is to be installed, be sure to install it in the DDR4_1 socket.
Dual channel memory architecture
Support for DDR4 2933/2666/2400/2133 MHz memory modules
Support for non
ECC memory modules
(Please refer "Memory Support List" for more information.)
Onboard Graphics
Integrated Graphics Processor
Intel® HD Graphics support:
1 x D
Sub port, supporting a maximum resolution of [email protected] Hz
1 x HDMI port, supporting a maximum resolution of [email protected] Hz * Support for HDMI 2.0 version and HDCP 2.3.
1 x DisplayPort, supporting a maximum resolution of [email protected] Hz * Support for DisplayPort 1.2 version and HDCP 2.3
(Graphics specifications may vary depending on CPU support.)
Audio
Realtek® Audio CODEC
High Definition Audio
2/4/5.1/7.1
channel * To configure 7.1
channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE's website for details on configuring the audio software.
